Dimensions
28.92"L x 27.49"W x 22.45"H
(73.5cm x 69.8cm x 57cm

Weight
110 lbs. (49.9kg)

Electrical
115 VAC, 60 cycle, 5 amps; overload protection built in 220 VAC, 50 cycle optional

Air Requirements
3 cfm at 90 psi

Product Sensing
Photoelectric

Communication Interface
High-speed serial interfaces: RS-232C and RS-422 with DB9F connector; RS-485 multi-drop capability; Zebra Net 10/100 print server

Product Sensing
Photoelectric

Processor
Rabbit 3000 Microprocessor

Printing Methods
Direct-thermal and thermal-transfer

Print Resolution
203, 300 or 600 dpi, dependent upon print engine selected

Label Roll Size
Maximum diameter 12.00" O.D. (304mm)

Labeling Speed
Contingent upon print engine and label size/content

Label Placement
Accurate to ±0.03" (.76mm) when labels are produced to specifications and product handling is controlled and consistent

Labels
Die-cut, waste removed with 0.125" (3mm) minimum separation between labels in running direction and 0.125" (3mm) maximum web over label width; direct or thermal-transfer

Labeling Software
Weber Legitronic® software

Print Characters & Bar Codes
Text: Selection of fonts, including OCR-A & B representation

Bar Codes: UPC-A/E, EAN-8/13, Code 39, I 2 of 5, Code 128, Codabar, MSI, 2 of 5, Code 93, UPC Bookland, Matrix 2 of 5, Postnet, UCC/EAN 128, PDF-417, Maxicode, Data Matrix
(Text and bar codes can be rotated 360 degrees; horizontal and vertical character expansion)
