Dimensions
29.92"L x 27.25"W x 28.25"H
(75.9cm x 69.2cm x 71.8cm)

Weight
220 lbs. (100kg)

Electrical
92 to 263 VAC, 50/60 hz, 5 amp

Air Requirements
3 cfm at 90 psi; compressed air must be clean, dry and oil-free (DiN isO 8573-1)

Product Sensing
Reflex sensor, light barrier, inductive or capacitive sensor, micro switch, floating contacts (PLC)

Communication Interface
RS-232-C; Centronics compatible

Product Sensing
Photoelectric

Label Gap
Minimum 1/8” (3mm)

Printing Methods
Direct-thermal and thermal-transfer

Print Resolution
203, 300 or 600 dpi, dependent upon print engine selected

Label Roll Size
Maximum diameter 13.75" O.D. (350mm)

Dispensing Output
Up to 40 labels per minute; dispensing output depends on label size, text change and dispensing stroke

Label Placement
Position accuracy of the dispensed labels: Standard: up to ± 0.03” (1mm) with controlled product handling. Optional: ± ).015 (0.5mm)

Labels
Die-cut, waste removed with 0.125" (3mm) minimum separation between labels in running direction and 0.125" (3mm) maximum web over label width; direct or thermal-transfer

Labeling Software
Weber Legitronic® software

Print Characters & Bar Codes
Text: Selection of fonts, including OCR-A & B representation

Bar Codes: UPC-A/E, EAN-8/13, Code 39, I 2 of 5, Code 128, Codabar, MSI, 2 of 5, Code 93, UPC Bookland, Matrix 2 of 5, Postnet, UCC/EAN 128, PDF-417, Maxicode, Data Matrix
(Text and bar codes can be rotated 360 degrees; horizontal and vertical character expansion)
